9 Example — Unspecified Connection from a PC Application

118

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

9.4.2 Edit the Network and Connection Project Engineering Data

Activity

Select “Edit network and connection configuration”.

Click on the “Finish” button to start NetPro.
