6 Using the CP 1616 as a PROFINET IO Controller/Device
71
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
6.1 Initialize CP 1616 (IP address and device name)
Assigning the IP address
Follow the steps outlined below
1. Open the SIMATIC Manager.
2. Select the menu command PLC
"
Ethernet
"
Assign Ethernet Address...
The “Assign Ethernet Address” menu opens.
3. Click on “Browse” in the “Select station to initialize” area and select the CP 1616.
4. In the “Set IP configuration” area, set the IP address of the CP 1616 and the subnet mask and
click “Assign IP Configuration”.
The IP address entered here must match the configured address.
5. In the “Assign device name” area, enter the device name of the CP 1616 and click “Assign
Name”.
The device name entered here must match the configured device name because when the CP
1616 is configured as a device, only the device name is relevant (not the IP address).
Note
If the CP 1616 was configured previously as a controller, you must first run a
complete memory reset before the device name can be changed.
Following every memory reset, the CP must be restarted (by STEP 7) otherwise
operation as a device is not possible!
