5 Project Engineering for the OPC Server
66
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Using the “Edit Plant Configuration” button, you obtain a list with all the devices
registered with the OPC server.
You can add others to this list or edit the parameters of the entered devices.
Device Profiles on the SIMATIC NET Software CD
Device profiles are available for the following modules on the SIMATIC NET
Software CD:
S CP 1613 - -> MIBII_V10.txt (supports only MIBII objects)
S OSM - -> Profil_OSM_V10.txt
S ELS - -> Profil_ELS_TP40_V10.txt
These files are stored in the following folder:
<installationdrive>\Programs\Siemens\simatic.ncm\S7data\SNMP\Profile
Note
Please read the detailed description of the parameters in the online help of the
dialog in STEP 7 / NCM PC.
5.5.2 SNMP Traps
Introduction
Traps are messages that can be sent to the OPC Server without it requesting
them. There are seven generic traps available on every SNMP-compliant device.
There are also device-specific traps that are described in the MIB file.
Generic Traps
Parameter Meaning
warmStart This is sent after a warm restart on the device.
coldStart This is sent after a cold restart on the device.
linkDown This is sent when a connection from the device
disconnects.
linkUp This is sent when a connection from the device is
established.
authenticationFailure This is sent when there was unauthorized access to the
device.
