16 Configuration Console Tool
229
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Activity
2 Depending on the mode set for the module, you can modify or only check the address
parameters.
S Configured mode
The parameters are set in the project engineering and cannot be changed.
S PG Operation
The parameters can be changed.
If you have selected “PG operation”, set the address parameters.
3 “Apply” the set values.
When you apply the values, you will see a message indicating that the module must be
restarted before the new values will become effective.
4 If you have installed NDIS1613, you will need to reboot your computer!
16.3.4 Assigning Access Points to the Individual Modules
By assigning an access point to an interface parameter assignment, you specify
the access path of an application. This assignment is necessary only for
applications that use the C interfaces (for example, SAPI S7, SAPI FMS, DP-Lib,
SR-Lib) and that use the application access point to address a device.
To operate the OPC server and for applications that handle their communication
over configured connections, it is not necessary to assign access points.
