16 Configuration Console Tool
230
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
If you want to assign an access point of an interface parameter assignment to a
module.....
Activity
1 Open the “Access points” folder in the navigation area.
2 Double-click on the access point you want to edit in the right-hand window.
3 Set the interface parameter assignment to be assigned to the access point.
If the module is used in the “configured mode”, the active interface parameter assignment is
fixed and cannot be modified.
4 “Apply” the settings.
Notice
Important for PROFIBUS modules:
With PROFIBUS modules, only one interface parameter assignment can be
activated at any one time. If you select a different interface parameter assignment
from the currently active interface parameter assignment when assigning an
access point, this interface parameter assignment is activated and assigned to
ALL access points!
