16 Configuration Console Tool
233
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
16.4 Diagnostics with “Configuration Console”
Overview
In diagnostics with “Configuration Console”, you can, for example, do the following
S Display the operability of the modules
S Display the PROFIBUS network parameters
S Display the available network nodes
S Display and set the Industrial Ethernet network parameters
S Display the version information of hardware and software
These options are described in the following sections 16.4.1 to 16.4.5.
16.4.1 Displaying the Operability of a PROFIBUS Module
Follow the steps outlined below...
Activity
1 Open the “Modules” folder in the navigation area.
Select the module you want to check.
Click on the “Network diagnostics” property.
To Next Page
