17 OPC Scout
249
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
The menu command has the following function
Print Item List to File Writes the currently displayed items and all values to a
file.
A file list box is displayed in which you can enter the file
name.
Print Project to File Writes information about servers, groups, and all items of
all groups to a file.
Exit Closes OPC Scout.
You will be asked whether or not you want to save the
current project.
17.11.2 View Menu
The View menu contains the following commands:
The menu command has the following function
Toolbar Toggles display of the toolbar on/off.
Status bar Toggles display of the status bar on/off.
Refresh Refreshes the display on the screen.
Options Opens the Options window in which you can decide
which attributes of the variables are displayed in the OPC
Scout window and can select the width of the columns.
17.11.3 Server Menu
The Server menu contains the following commands:
The menu command has the following function
Connect Establishes the connection from the OPC Scout to a local
or remote server.
Disconnect Terminates the connection from the OPC Scout to a
server.
Characteristics A dialog box opens in which you can display the standard
properties of the OPC Server.
