16 Configuration Console Tool

239

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

16.4.5 Displaying Version Information of Hardware and Firmware

Follow the steps outlined below...

Activity

1 Open the “Modules” folder in the navigation area.

Select the relevant module.

Click on the “Version” property object.

2 After the call, version information about the communication module is displayed.
