15 Symbol File Configurator Too
200
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Activity
4. The variable appears in the Selected Items part of the window. Add a symbolic name here.
Repeat steps 3 and 4 when necessary for other variables.
5. Close the “Add Items” dialog by clicking the “OK” button.
15.4.2 How to Insert a New Folder
Activity
1.
Select an element in the left-hand area of the program window. The program always
creates a new folder below the selected element.
2. Select the “New Folder” command in the “Edit” menu.
or
Select “New Folder” in the context-sensitive menu (right mouse button)
or
Click on the following button:
3. The “Insert New Folder” dialog opens.
Here, enter a name for the new folder and confirm your entry by clicking the “OK”
button.
