15 Symbol File Configurator Too
201
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
15.4.3 How to Add a Name Space Prefix
Activity
1.
Select “Add/Change Prefix” in the “Edit” menu.
The “Change Prefix” dialog appears.
2. Here, enter a name for the prefix or change an existing prefix name and confirm your entry by
clicking the “OK” button.
If you want to delete the prefix, click the “Delete Prefix” button.
15.4.4 How to Delete Folders or Symbols
Activity
1. Select the folder or symbol you want to delete in the structure view.
2. Select “Remove Element” in the “Edit” menu.
or
Select “Remove Element” in the context-sensitive menu (right mouse button)
Remember that when you delete a folder, you also delete all the elements contained in the
folder (subfolders and symbols).
15.4.5 How to Import a Symbol File
Activity
1. In the OPC Address Space dialog, select the context-sensitive menu “Import from CSV File”.
A dialog appears in which you can select a file.
2. Select the file you want to import and confirm your entries with the “OK” button.
