13 SIMATIC NCM PC Project Engineering Tool
178
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Follow the steps outlined below:
6. Save and compile the configuration.
In the next section, the PC station will be assigned to a DP master system, in the
example also a PC station.
Follow the steps below:
Follow the steps outlined below:
1. In HW Config, open the configuration of the PC station set up with a DP master system.
2. Select the entry ”PC station as DP slave” in the catalog under ”PROFIBUS-DP” and drag the
entry to the DP master system.
