13 SIMATIC NCM PC Project Engineering Tool
186
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
S Online mode - local (configuration station and PC station identical)
Download
This situation occurs when the configuration system is installed on the PC station
(engineering station).
In this case, the configuration data are transferred directly over an internal PC
connection. Within the configuration system you still use the known mechanisms
for accessing the target system as in case a).
Follow the steps below:
Procedure for “Downloading Project Engineering Data to the PC
Station” -
Online - Local
Tool
1. Make sure that the following requirement is met:
The access point of the application must be set as follows:
S7ONLINE (STEP7) -> PC internal (local)
Set PG/PC
Interface
2. Select the station you want to download to. NCM PC / STEP 7
3. Download the configuration data with PLC -> Download NCM PC / STEP 7
