16 Configuration Console Tool
227
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
If you want to display and set the Industrial Ethernet network parameters of the
CP 1613 .....
Activity
1 Open the “Modules” folder in the navigation area.
Select the “CP 1613” Ethernet module.
Click on the “Network parameters” property object.
2 If you want to modify the network parameters:
Activate the required option button for each parameter.
The default for all parameters is “Automatic”.
3 “Apply” the settings.
When you apply the values, you will see a message indicating that the module must be
restarted before the new values will become effective.
4 If you have installed NDIS1613, you will need to reboot your computer!
