1 Welcome to Advanced PC Configuration
23
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
S Case b) Initial configuration with existing project engineering (XDB file)
With this method, it is assumed that the PC station and its components and
applications is first created in project engineering in STEP 7 / NCM PC. This
produces a database (XDB file) that is then available for the commissioning
engineer for the initial configuration.
The advantage of this is that the project engineering data and the PC
configuration are consistent and the total effort is minimal.
Step How does it work? Tool
Project engineering
(as prerequirement for
initial configuration)
Steps in project engineering of the PC
station:
S Create the PC station in NCM PC
NCM PC / STEP 7
S SIMATIC Manager
S Enter modules and applications S HW Config
S Create connections in NetPro
S Use symbols (in the project
engineering of the OPC server)
S NetPro
S HW Config
S Project engineering data of the PC
station is saved in an XDB file .
S SIMATIC Manager
1. Installing SIMATIC
NET software
Install the SIMATIC NET software
based on the installation instructions
SIMATIC NET CD / Windows
2. Installing the
hardware (PC
modules)
Install the communication module in the
PC station
Refer to the documentation on the
CP
3. Initial configuration Import XDB
Project engineering data is transferred
to the PC station.
Station Configuration Editor
(later download of project
engineering data also possible
with NCM PC / STEP 7)
Result:
PC station is ready for productive communication
4. Testing the
configuration
Configuration Console Configuration Console
