17 OPC Scout
244
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Activity
1. Select the required group for which you want to browse the process space of the server in the
Servers and Groups Navigator of the OPC Scout.
2. Open the Item menu and select the Add Item(s) command.
The OPC Navigator window opens.
The left-hand column of the window displays the hierarchical structure of the process space.
You can double-click to open the lower levels.
3. Select the level you want to display for the variables. All variables for the level are displayed in
the middle column.
Process Space Display
Variable Display
Variables that will be added
to the current group.
To Next Page
