2 Getting Started “Configured Mode”
40
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
How to Make the Initial Configuration without an XDB File
4 In the properties dialog that opens, give the module an address.
In some cases, you can also set further module parameters, for example bus parameters,
(mandatory with PROFIBUS).
5 Repeat the steps for all other modules that exist in the local station and that you want to
operate in configured mode.
6 Using the “Add” button, add the applications to be operated on the station.
7 Repeat the steps for all other applications you want to use for the configured mode.
Result:
PC station is configured with modules and applications and ready
to receive project engineering data (select online mode)
Tip:
You will also find this procedure in our example “OPC Configuration for
PROFIBUS”; see Section 8.
Where to we go from here?
In the next step, you supply the PC station with project engineering data.
