8 Example — OPC Application for PROFIBUS-DP

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

Procedure for “Initial Configuration”

Check whether the settings of the module match the local configuration.

Confirm the configuration with “OK”.

Result: The CP 5613 is in the “configured mode”.

PC configuration is complete.
