Troubleshooting
B-4
High Speed Counter Encoder Module User Manual
B.3 Terminal Block Worksheets
Terminal
block worksheets are provided in Figure B-2 and Figure B-4 for
you to record the wiring for this module.
Side-accessible T
erminal Block
(PPX:2587705–8010)
Back-up
Power +12V
Back-up Power R
TN
Ch1 A+
Ch1 A–
Ch1 B+
Ch1 B–
Ch1 C+
Ch1 C–
Ch1 D+
Ch1 D–
Output 1
Output 2
Ch1 INDEX+
Ch1 INDEX–
Ch1 RESET+
Ch1 RESET–
Ch1 INHIBIT+
Ch1 INHIBIT–
Ch2 A–
Ch2 B+
Ch2 B–
Ch2 C+
Ch2 C–
Ch2 D+
Ch2 D–
PWR +24V
RTN
Ch2 INDEX+
Ch2 INDEX–
Ch2 RESET+
Ch2 RESET–
Ch2 INHIBIT+
Ch2 INHIBIT–
Ch2 A+
Output 3
Output 4
Output 5
Output 6
Output 7
Output 8
Figur
e B-1
Typical
Side-Accessible T
er
minal Block
