Specifications
C-8
High Speed Counter Encoder Module User Manual
Output Specifications (continued)
The
module software cycle time is less than 1 millisecond. The typical
response times of input to output signals are listed in T
able C-4.
T
able C-4
Module Response T
imes
Counter 1 to output 1 Less than 10 microseconds
Counter 1, Preset 2 to output 1 Less than 1 millisecond
Counter 1, Preset 2 to output 2 Less than 1 millisecond
Counter 2 to output 3 Less than 10 microseconds
Counter 3 to output 4 Less than 10 microseconds
Counter 4 to output 5 Less than 10 microseconds
Counter 4, Preset 6 to output 5 Less than 1 millisecond
Counter 4, Preset 6 to output 6 Less than 1 millisecond
Counter 5 to output 7 Less than 10 microseconds
Counter 6 to output 8 Less than 10 microseconds
The
Backup Power Supply must be rated at 12 V
"
20
per cent at 200
milliamperes maximum. The supply must be a Class 2 power supply
.
Module Response
Times
Backup Power
Supply
Specifications
