Siemens SIMATIC TI505 - Figure 1-10 24-Bit Counter Output up Counting; Figure 1-11 24-Bit Counter Output down Counting

To Next Page

To Previous Page

Product Overview

1-15

High Speed Counter Encoder Module User Manual

Carry

oggle

Rollover

Compare T

oggle

Latch

Compare

Pulse Input

–3 –2 –1 0 1 2 3 4 5 6 7

Figure 1-10 24-Bit

Counter Output Up Counting

Borrow

oggle

Rollover

Compare T

oggle

Latch

Compare

Pulse Input

7 6 5 4 3 2 1 0 –1 –2

Figure 1-11 24-Bit

Counter Output Down Counting
