Installing the Module

2-9

High Speed Counter Encoder Module User Manual

Figure 2-7

shows an example of wiring mechanical switch inputs. (Note that

with mechanical switches, the contacts can “bounce” when switched.)

A+

A–

Module

OCI

Constant

current

load

A+

A–

Module

OCI

Constant

current load

Figure 2-7 Mechanical

Switches
