Product Overview
1-16
High Speed Counter Encoder Module User Manual
24-Bit Counters Non-Quadrature Mode Outputs (continued)
In
non-recycle counting mode, Compare, Carry
, and Borrow
pulses
are not
generated. Carry
Toggle
and Borrow
Toggle
signals are the cycle completion
indicators. At the end of a cycle, additional input count pulses are ignored.
One of the following conditions is required to restart the counter:
•
An external INDEX pulse (when WY21.07, or WY27.07, or both are
set).
•
A PLC counter reset (WY19.02 or WY19.06).
•
Setting the program flag (WY20.01).
In Divide-by-N counting mode, Compare, Compare Latch, or Compare
T
oggle signals are not generated. The counter starts at the preset value and
counts to an overflow or underflow, generating a Carry or Borrow
.
W
e recommend that Divide-by-N counting be done in the down count
direction only
, with the Borrow T
oggle signaling the underflow event. In the
non-quadrature, recycle counting mode, the Carry and Borrow pulses are
externally available, and can be used to cascade to another counter input.
T
able 1-1
Binary Counting Outputs
Recycle Mode Non-Recycle Mode
Quadrature Non-Quadrature Quadrature Non-Quadrature
Compare Compare Carry
T
oggle Carry Toggle
Compare Toggle Compare Toggle Compare Toggle Borrow Toggle Borrow Toggle
Compare Latch Compare Latch Compare Latch
Rollover Carry and Borrow
Pulse
T
able 1-2
Divide-by-N
Counting Outputs
Recycle Mode Non-Recycle Mode
Quadrature Non-Quadrature Quadrature Non-Quadrature
Compare Carry
T
oggle Carry Toggle Carry Toggle Carry Toggle
Compare Toggle Borrow Toggle Borrow Toggle Borrow Toggle Borrow Toggle
Compare Latch
Rollover Carry and Borrow
Pulse
Outputs
in
Non-r
ecycle Mode
Outputs in
Divide-by-N Mode
