High Speed Counter Encoder Module User Manual
Preface
This manual describes the SIMA TIC TI505  High Speed Counter Encoder
Module. The following major topics are covered:
• Overview of product features.
• Hardware installation and wiring procedures.
• Quick start procedure using the default configuration.
• Basic concepts of operation.
• Configuring optional modes of operation.
• Applications.
• Troubleshooting.
•
Product specifications.
Additional manuals that have relevant information include the following:
• SIMA TIC TI505 Programming Reference Manual
(PPX:505–8104–4 or later)
• SIMA TIC TI505 TISOFT2  Release 4.3 User Manual
(PPX:TS505–8101–4 or later)
• SIMA TIC TI505 Input/Output User Manual (PPX:505–8105–x)
Refer to material in these manuals as necessary for additional information
about using your TI505 High Speed Counter Encoder module.
NOTE: The listed CPU Software releases may not properly allow the module
to update the WX words during an immediate I/O Read cycle. If you use one
of the releases listed below , use an immediate I/O W rite following the
immediate I/O Read to correct a possible conflict:
• SIMATIC TI545  , Release 2.1.1 and earlier .
• SIMATIC TI555  , Release 1.1.2 and earlier .
