Specifications
C-2
High Speed Counter Encoder Module User Manual
C.1 Environmental Specifications
T
able C-1
Physical
and Envir
onmental Specifications
Minimum torque for bezel screws and connector screws
2.6 in-lb (0.3 N-m)
Maximum torque for bezel screws and connector screws
5.2 in-lb (0.6 N-m)
Input signal wiring Shielded, twisted pair cable
(12–26 A
WG or 0.16–3.2 mm
2
, stranded or solid)
Spade lug for use with connector 2587705–8010
Amp part number 321462
Ring lug for use with connector 2587705–8010
Amp part number 327891
Module power required from base 2.0 W at 5 VDC
Operating temperature
0 to 60
°
C (32 to 140
° F)
Storage temperature
–40 to +70
°
C (–40 to 158
° F)
Relative humidity 5% to 95% non-condensing
Pollution degree
2, IEC 664, 664 A
Vibration Sinusoidal
IEC 68-2-6, Test Fc
0.15 mm peak-to-peak, 10–57 Hz;
1.0 g, 57–150 Hz
Random
IEC 68-2-34, T
est Fdc,
equivalent to NAVMA
T P–9492
0.04 g
2
/Hz, 80–350 Hz
3 dB/octave rolloff 80–20 Hz, 350–2000 Hz
Impact Shock
IEC 68-2-27; T
est Ea
Electrostatic discharge IEC 801, Part 2, Level 4, (15kV)
Noise immunity, conducted on Series 505 power supply
and user power supply
IEC 801, Part 4, Level 3
IEC255–4 Appendix E
EEC 4517/79 Com(78) 766 Final Part 4
MIL STD 461B CS01, CS02 and CS06
Noise immunity, radiated IEC 801, Part 3, Level 3,
MIL STD 461B RS01, and RS02
Isolation,
inputs to controller
inputs to inputs
inputs to outputs
all outputs to controller
back-up power to controller, inputs, and outputs
1500 V
rms
1500 V
rms
1500 V
rms
1500 V
rms
1500 V
rms
Isolation, output to output No isolation: common power supply and return
Corrosion protection All parts of corrosion-resistant material, plated, or
painted as corrosion protection
