A
A.1 Parameter list
A-853
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
1800 Function generator control
Min Standard Max Unit Data type Effective
–40 0 2 – Integer16 immed.
Note: refer to the index entry ”Function generator”
1804 Function generator operating mode
Min Standard Max Unit Data type Effective
1 3 5 – Unsigned16 immed.
Note: refer to the index entry ”Function generator”
1805 Function generator curve shape
Min Standard Max Unit Data type Effective
1 1 5 – Unsigned16 immed.
Note: refer to the index entry ”Function generator”
1806 Start-up function amplitude
Min Standard Max Unit Data type Effective
–1600.0 5.0 1600.0 % Floating Point immed.
Note: refer to the index entry ”Function generator”
1807 Start-up function offset
Min Standard Max Unit Data type Effective
–1600.0 0.0 1600.0 % Floating Point immed.
Note: refer to the index entry ”Function generator”
1808 Function generator limitation
Min Standard Max Unit Data type Effective
0.0 100.0 1600.0 % Floating Point immed.
Note: refer to the index entry ”Function generator”
1809 Function generator 2nd amplitude (staircase)
Min Standard Max Unit Data type Effective
–1600.0 7.0 1600.0 % Floating Point immed.
Note: refer to the index entry ”Function generator”
1810 Function generator period
Min Standard Max Unit Data type Effective
1 1000 65535 ms Unsigned16 immed.
Note: refer to the index entry ”Function generator”
1811 Function generator, pulse width (squarewave)
Min Standard Max Unit Data type Effective
0 500 65535 ms Unsigned16 immed.
Note: refer to the index entry ”Function generator”
1812 Start-up function, bandwidth (FFT)
Min Standard Max Unit Data type Effective
1 4000 8000 Hz Unsigned16 immed.
Note: refer to the index entry ”Function generator”
1813 Start-up function, ramp-up time to P1400
Min Standard Max Unit Data type Effective
0.0 32.0 100000.0 ms Floating Point immed.
Note: refer to the index entry ”Function generator”
04.05
