A
A.1 Parameter list
A-855
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
1826 Status test socket 1
Min Standard Max Unit Data type Effective
0 1 1 – Unsigned16 immed.
This parameter defines the status of test socket 1 for this drive.
0 test socket is inactive
1 test socket is active
As always only one drive can output one value at a test socket, when changing the parameter
in one drive, the parameter in the other drive is appropriately changed.
Note:
On a 2-axis module, the test sockets are pre-set as follows after the first start-up:
Drive A: Test socket 1 = active (P1826 = 1) and test socket 2 = inactive (P1836 = 0)
Drive B: Test socket 1 = inactive (P1826 = 0) and test socket 2 = active (P1836 = 1)
(refer to the index entry ”Test sockets”)
1830 Signal number test socket 2
Min Standard Max Unit Data type Effective
0 14 530 – Unsigned16 immed.
Description, refer to that for P1820.
1831 Shift factor test socket 2
Min Standard Max Unit Data type Effective
0 12 47 – Unsigned16 immed.
Description, refer to that for P1821.
1832 Offset test socket 2
Min Standard Max Unit Data type Effective
–128 0 127 – Integer16 immed.
Description, refer to that for P1822.
1833 Segment address test socket 2
Min Standard Max Unit Data type Effective
0 0 1 – Unsigned16 immed.
Note: Internal Siemens
1834 Offset address test socket 2
Min Standard Max Unit Data type Effective
0 0 FFFFFF Hex Unsigned32 immed.
Note: Internal Siemens
1836 Status test socket 2
Min Standard Max Unit Data type Effective
0 1 1 – Unsigned16 immed.
Description, refer to that for P1826.
A Lists
01.99
! 611ue diff !
04.05
