6.7 Communication according to PROFIdrive
Converter cabinet units
Operating Instructions, 07/2016, A5E03347396A
321
Note
Easy method for creating extended telegram interconnections
If p0922 = 999, a telegram can be selected in p2
079. A telegram interconnection is
automatically made and blocked. However, the telegram can also be extended.
This is an easy method of creating extended telegram interconnections on the basis of
existing telegrams.
Structure of the telegrams
Table 6- 15 Structure of the telegrams
1 STW1 NSOLL_A
2
3
4
Further assignment, see FP2420
20
ZSW1 NIST_A_
IAIST_
MIST_
PIST_
MELD_
220 STW1_
NSOLL_B STW2_BM M_ADD M_LIM free free free free
ZSW1_
NIST_A IAIST MIST WARN_
FAULT_
free free free
352
ZSW1 NIST_A_
GLATT
IAIST_
GLATT
MIST_
GLATT
WARN_
CODE
FAULT_
CODE
999
