Machine and Setting Data
D.2 Channel-specific machine data
04.07
D-233
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
22900 STROKE_CHECK_INSIDE
MD number Determine enternal/external protection zone
Default setting: 0 Minimum input limit: 0 Maximum input limit: 1
Changes effective after POWER ON Protection level: 2/7 Unit: --
Data type: BYTE Applies with effect from SW version: 5.2
Meaning: This machine data applies in combination with external programming languages.
It is effective with $MN_MM_EXTERN_LANGUAGE = 1.
It defines whether protection zone 3 is an internal or external protection zone.
Meaning:
0: Protection zone 3 is an internal protection zone
1: Protection zone 3 is an external protection zone
This MD cannot SINUMERIK 802D sl.
22910 WEIGHTING_FACTOR_FOR_SCALE
MD number Input unit for scaling factor
Default setting: 0 Minimum input limit: 0 Maximum input limit: 1
Changes effective after POWER ON Protection level: 2/7 Unit: --
Data type: BOOLEAN Applies with effect from SW version: 5.2
Meaning: This machine data applies in combination with external programming languages. It is active
with $MN_MM_EXTERN_LANGUAGE = 1.
It defines the unit for the scale factor P and the axial scale factors I, J, K
Meaning:
0: Scale factor in 0.001
1: Scale factor in 0.00001
22914 AXES_SCALE_ENABLE
MD number Enable axial scaling (G51)
Default setting: 0 Minimum input limit: 0 Maximum input limit: 1
Changes effective after POWER ON Protection level: 2/7 Unit: --
Datentype: BOOLEAN gültig ab SW--Stand: 5.2
Meaning: This MD enables axial scaling.
Meaning:
0: Axial scaling not possible
1: Axial scaling possible, (MD DEFAULT_SCALE_F ACTOR_AXIS becomes effective)
