Data Fields, Lists
E.2 Setting data
04.07
E-241
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Channel--specific ($MC_ ... )
28080 NUM_USER_FRAMES Number of zero offsets
28082 MM_SYSTEM_FRAME_MASK System frames (SRAM)
29210 NUM_PROTECT_AREA_ACTIVE Activate protection zone
34100 REFP_SET_POS[0] Reference position / not used when absolute
measuring system is applied
35000 SPIND_ASSIGN_TO_MACHAX assign spindle / machine axis
E.2 Setting data
Number Identifier Name Refer--
ence
Axis--specific
43120 $SC_DEFAULT_SCALE_FACTOR_AXIS Default axial scale factor when G51 active
43240 $SA_M19_SPOS Position of spindle when programming M19
42890 $SA_M19_SPOSMODE Positioning mode of spindle when comman-
ding M19
Channel--specific
42110 $SC_DEFAULT_FEED Default value for path feed V1
42140 $SC_DEFAULT_SCALE_FACTOR_P Default scale factor for address P
42150 $SC_DEFAULT_ROT_FACTOR_R Default angle of rotation R
42520 $SC_CORNER_SLOWDOWN_START Distance before corner
42522 $SC_CORNER_SLOWDOWN_END Distance after corner
42524 $SC_CORNER_SLOWDOWN_OVR Feed override at corner with G62
42526 $SC_CORNER_SLOWDOWN_CRIT Criterium for corner detection with G62
43340 $SC_EXTERN_REF_POSITION_G30_1 Reference point position for G30.1
