SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Alarms
If error states are detected in cycles, an alarm is generated and cycle execution is interrup-
ted.
The cycles continue to output messages in the dialog line of the control. These messages do
not interrupt execution.
Alarms with numbers between 61000 and 62999 are generated in the cycles This number
range is subdivided further according to alarm reactions and cancelation criteria.
Table F-1 Alarm number and alarm description
Alarm no.
Brief description Source Explanation/remedy
General alarms
61001 Pitch of thread not correct CYCLE376T Pitch of thread is not specified
correctly
61003 No feed programmed in cycle CYCLE371T, CYCLE374T,
CYCLE383T, CYCLE384T,
CYCLE385T, CYCLE381M,
CYCLE383M, CYCLE384M,
CYCLE387M
No feed F word was program-
med in the calling block before
the cycle call, see standard Sie-
mens cycles
61004 Configuration of geometry axis
not correct
CYCLE328 The order of the geometry axes
is incorrect, see standard
Siemens cycles
61101 Reference plane improperly de--
fined
CYCLE375T, CYCLE81,
CYCLE83, CYCLE84, CYCLE87
See standard Siemens cycles
61102 No spindle direction program-
med
CYCLE371T, CYCLE374T,
CYCLE383T, CYCLE384T,
CYCLE385T, CYCLE381M,
CYCLE383M, CYCLE384M,
CYCLE387M
Spindle direction M03 or M04
missing, see standard Siemens
cycles
61107 First drilling depth incorrectly de-
fined
First drilling depth counter to to--
tal drilling depth
61603 Grooving incorrectly defined CYCLE374T Grooving depth value 0
61607 Start point incorrect CYCLE376T The start point is not outside of
theareatobemachined
61610 No in--feed programmed CYCLE374T In--feed value = 0
ISO alarms
61800 External CNC system missing CYCLE300, CYCLE328,
CYCLE330, CYCLE371T,
CYCLE374T, CYCLE376T,
CYCLE383T, CYCLE384T,
CYCLE385T, CYCLE381M,
CYCLE383M, CYCLE384M,
CYCLE387M
Machine data for external lan--
guage MD18800:
$MN_MM_EX --TERN_ LAN-
GUAGE or option bit 19800
$ON_EXTERN_LAN--G UAGE is
not set
