SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Table F-1 Alarm number and alarm description, continued
Alarm no. Explanation/remedySourceBrief description
61801 Incorrect G code selected CYCLE300, CYCLE371T,
CYCLE374T, CYCLE376T,
CYCLE383T, CYCLE384T,
CYCLE385T
An illegal numerical value for the
CNC system was programmed
in the program call
CYCLE300<value> or in the cy-
cle setting data an incorrect va-
lue for the G code system was
specified.
61802 Incorrect axis type CYCLE328, CYCLE330 The programmed axis is
assigned to a spindle
61803 Programmed axis does not exist CYCLE328, CYCLE330 The programmed axis does not
exist in the system. Check
MD20050--20080
61804 Programmed position beyond re-
ference point
CYCLE328, CYCLE330 The programmed intermediate
position or current position is
located behind the reference
point
61805 Value programmed in absolute
and incremental dimensions
CYCLE328, CYCLE330, CY-
CLE371T, CYCLE374T, CY-
CLE376T, CYCLE383T, CY-
CLE384T, CYCLE385T
The intermediate position is
programmed using both abso-
lute and incremental dimensions
61806 Incorrect axis assignment CYCLE328 The order of the axis assignment
is incorrect
61807 Incorrect spindle direction pro--
grammed
CYCLE384M The programmed spindle direc--
tion conflicts with the spindle
directionusedforthecycle
61808 Final drilling depth or single dril--
ling depth missing
CYCLE383T, CYCLE384T,
CYCLE385T, CYCLE381M,
CYCLE383M, CYCLE384M,
CYCLE387M
Total depth Z or single drilling
depth Q missing from G8x block
(first call of cycle)
61809 Drilling position not admissible CYCLE383T, CYCLE384T,
CYCLE385T
61810 ISO G cde not possible CYCLE383T, CYCLE384T,
CYCLE385T
61811 ISO axis designation not admis-
sible
CYCLE328, CYCLE330.
CYCLE371T, CYCLE374T,
CYCLE376T, CLE383T,
CYCLE384T, CYCLE385T
The calling NC block contains
an ISO axis designation which
is not admissible
61812 Incorrect numeral value(s) in
cycle call
CYCLE371T, CYCLE376T, The calling NC block contains
a numeral value which is not
admissible
61813 Incorrect GUD value CYCLE376T Not admissable numeral value
in cycle setting data
61814 Polar coordinatea not possible CYCLE381M, CYCLE383M,
CYCLE384M, CYCLE387M
61815 G40 not active CYCLE374T, CYCLE376T G40 was not active prior to the
cycle call
