Siemens SINUMERIK 802D sl Programming Manual

Machine and Setting Data
D.1 Machine/Setting data
04.07
D-216
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
10652 CONTOUR_DEF_ANGLE_NAME
MD number Definable name for angle in the contour short description
Default setting: ”ANG” Minimum input limit: -- Maximum input limit: --
Changes effective after Power On Protection level: 2/7 Unitt: --
Datentype: STRING Applies with effect from SW version: 5
Meaning: The setting is effective for Siemens G code programming only, i.e. G290.
The name used to program the angle in the contour short description is definable. This
allows, for example, identical programming in different language modes:
If the angle is named “A”, it is programmed in the same way with Siemens and ISO Dia--
lect0.
The name must be unique, i.e. axes, variables, macros, etc. must not exist with the same
name.
This MD cannot SINUMERIK 802D sl.
10654 RADIUS_NAME
MD number Definable name for radius non--modally in the contour short description
Default setting: “RND“ Minimum input limit: -- Maximum input limit: --
Changes effective after Power On Protection level: 2/7 Unit: --
Data type: STRING Applies with effect from SW version: 5
Meaning: The name used to program the radius in the contour short description is definable. This
allows, for example, identical programming in different language modes:
If the radius is named “R“, it is programmed in the same way with Siemens and ISO Dia--
lect0.
The name must be unique, i.e. axes, variables, macros, etc. must not exist with the same
name.
The setting is effective for Siemens G code programming, i.e. G290.
This MD cannot SINUMERIK 802D sl.
10656 CHAMFER_NAME
MD number Definable name for chamfer in the contour short description
Default setting: ”CHR” Minimum input limit: -- Maximum input limit: --
Changes effective after Power On Protection level: 2/7 Unit: --
Data type: STRING Applies with effect from SW version: 5
Meaning: The name used to program the chamfer in the contour short description is definable. This
allows, for example, identical programming in different language modes:
If the chamfer is named “C”, it is programmed in the same way with Siemens and ISO Dia--
lect0.
The name must be unique, i.e. axes, variables, macros, etc. must not exist with the same
name.
The setting is effective for Siemens G code programming, i.e. G290.
The chamfer in the original direction of movement. Alternatively, the chamfer length can be
programmed with the name CHF.
This MD cannot SINUMERIK 802D sl.
