Siemens SINUMERIK 802D sl Programming Manual

Movement Control Commands
3.1 The coordinate system
04.07
3-52
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Creates $MC_MM_SYSTEM_FRAME_MASK Bit 8 = 1
Reset behavior Delete frame
$MC_CHSFRAME_RESET_MASKBit 8 = 0
G51.1: Mirroring
G51.1 X Y $P_ISO1FRAME
Component TRANS, MIRROR
Creates $MC_MM_SYSTEM_FRAME_MASK Bit 7 = 1
Reset behavior Delete frame
$MC_CHSFRAME_RESET_MASKBit 7 = 0
G92: Set actual value
G92XYR $P_SETFRAME
Component TRANS
Creates $MC_MM_SYSTEM_FRAME_MASK Bit 0 = 1
Reset behavior Frame is maintained after RESET
$MC_CHSFRAME_RESET_MASKBit 0 = 1
G10L2P0
G10L2P0 $P_EXTFRAME
Component TRANS
Creates $MC_MM_SYSTEM_FRAME_MASK Bit 1 = 1
Reset behavior Delete frame
$MC_CHSFRAME_RESET_MASKBit 1 = 0
If all frames are created, it is no longer necessary for the ISO mode that the fra-
mes are configured using the FINE component. The machine data 18600:
$MN_MM_FRAME_FINE_TRANS need not be set to ”1”. If you switch from the
ISO mode to the Siemens mode and if the Siemens mode uses a function which
requires a fine offset (e.g. G58, G59), $MN_MM_FRAME_FINE_TRANS must re-
main ”1”.
3.1.7 Local co o rdinate system (G52)
