Siemens SINUMERIK 802D sl Programming Manual

Enhanced Level Commands
4.1 Program support functions (1)
04.07
4-128
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
4.1.15 Program example using tool length offset and canned cycles
# 1 to 6 Drilling of a 10 mm diameter hole
# 7 to 10 Drilling of a 20 mm diameter hole
# 11 to 13 Boring of a 95 mm diameter hole (depth 50 mm)
Reference position
Y
X
Y
X
350
100
100
100
100
400 150 250 250 150
200
#1
#2
#3
#7
#8
#11
#12
#13
#6
#5
#4
#10
#9
Retract position
250
50
50
30
20
T11 T15 T30
Initial level
200
190
150
Fig. 4-21 Program example (drilling cycle)
