Siemens SINUMERIK 802D sl Programming Manual

G Code Table
C.1 G code table
04.07
C-211
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
G Code Table
Appendix C describes the G codes and the functions.
C.1 G code table
Table C-1 G code table
G code Description 840D sl 802D sl
Group 1
G00
1)
1
Rapid traverse x x
G01 2 Linear motion x x
G02 3 Circle/helix, clockwise x x
G02.2 6 Involute interpolation, clockwise x x
G03 4 Circle/helix, counterclockwise x x
G03.2 7 Involute interpolation, counterclockwise x x
G33 5 Thread cutting with constant lead x x
Group 2
G17
1)
1
XY plane x x
G18 2 ZX plane x x
G19 3 YZ plane x x
Group 3
G90
1)
1
Absolute programming x x
G91 2 Incremental programming x x
Group 4
G22 1 Working area limitation, protection zone 3 on x x
G23
1)
2
Working area limitation, protection zone 3 off x x
Group 5
G93 3 Inverse time feed (rev/min) x x
G94
1)
1
Feed in [mm/min, inch/min] x x
G95 2 Feed in [mm/rev, inch/rev] x x
Group 6
G20
1)
(G70) 1
Input system inch x x
G21 (G71) 2 Input system metric x x
C
