Siemens SINUMERIK 802D sl Programming Manual

G Code Table
C.1 G code table
04.07
C-212
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Table C-1 G code table
G code 802D sl840D slDescription
Group 7
G40
1)
1
Deselect cutter radius compensation x x
G41 2 Compensation to left of contour x x
G42 3 Compensation to right of contour x x
Group 8
G43 1 Tool length compensation positive on x x
G44 2 Tool length compensation negative on x x
G49
1) 3
Tool length compensation off x x
Group 9
G73 1 High speed deep hole drilling cycle with chipbreaking x x
G74 2 Counterclockwise tapping cycle x x
G76 3 Fine drilling cycle x x
G80
1)
4
Cycle off x x
G81 5 Counterbore drilling cycle x x
G82 6 Counterboring drilling cycle x x
G83 7 Deep hole drilling cycle with swarf removal x x
G84 8 Clockwise tapping cycle x x
G85 9 Drilling cycle x x
G86 10 Drilling cycle, retract using G00 x x
G87 11 Back boring cycle x x
G89 12 Drilling cycle, retract using G01 x x
Group 10
G98
1)
1
Return to starting point for fixed cycles x x
G99 2 Return to point R for fixed cycles x x
Group 11
G50
1)2)
1
Scaling off x x
G51
2) 2
Scaling on x x
Group 12
G66
2)
1
Modal macro call x x
G67
1)2)
2
Delete modal macro call x x
Group 13
G96 1 Constant cutting rate on x x
G97
1)
2
Constant cutting rate off x x
Group 14
G54
1)
1
Select zero offset x x
G55 2 Select zero offset x x
