E-239

SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition

Data Fields, Lists

E.1 Machine data

Number Identifier Name Refer-

ence

General ($MN_ ... )

10604 WALIM_GEOAX_CHANGE_MODE Work area limitation when switching geometri-

cal axes

10615 NCFRAME_POWERON_MASK Delete global base frames on Power On K2

10652 CONTOUR_DEF_ANGLE_NAME Definable name for angle in the contour short

description

10654 RADIUS_NAME Definable name for radius non--modally in the

contour short description

10656 CHAMFER_NAME Definable name for chamfer in the contour

short description

10704 DRYRUN_MASK Activating dry run feed

10706 SLASH_MASK Activating the block skip function

10715 M_NO_FCT_CYCLE[n]: 0, ..., 0 M function number for tool change cycle call

10716 M_NO_FCT_CYCLE_NAME[ ] Name of tool--changing cycle for M functions-

from MD $MN_MFCT_CYCLE

10717 T_NO_FCT_CYCLE_NAME Name for tool--changing cycle with T no.

10718 M_NO_FCT_CYCLE_P AR M function substitution with parameters

10719 T_NO_FCT_CYCLE_MODE Parameterization of T function substitution

10760 G53_TOOLCORR Behaviour of G53, G153 and SUP A

10800 EXTERN_CHAN_SYNC_M_NO_MIN First M code for channel synchronization

10802 EXTERN_CHAN_SYNC_M_NO_MAX Last M code for channel synchronization

10804 EXTERN_M_NO_SET_INT ASUP activation M code

10806 EXTERN_M_NO_DISABLE_INT ASUP deactivation M code

10808 EXTERN_INTERRUPT_BITS_M96 Interrupt program execution (M96)

10810 EXTERN_MEAS_G31_P_SIGNAL Measuring input assignment for G31 P..

10814 EXTERN_M_NO_MAC_CYCLE Macro call via M function

10815 EXTERN_M_NO_MAC_CYCLE_NAME UP name for M function macro call

10818 EXTERN_INTERRUPT_NUM_ASUP Interruptnumber for ASUP start (M96)

10820 EXTERN_INTERRUPT_NUM_RETRAC Interruptnumber for retract (G10.6)

10880 EXTERN_CNC_SYSTEM External control system whose programs are

to be executed
