Machine and Setting Data
D.4 Channel-specific setting data
04.07
D-237
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
D.4 Channel-specific setting data
42110 DEFAULT_FEED
SD number Default value for path feed
Default setting: 0 Minimum input limit: 0 Maximum input limit: --
Changes effective IMMEDIATELY Protection level: 7/7 Unit: --
Data type: DOUBLE Applies with effect from SW version: 5.2
Meaning: If no path feed is programmed in the part program, the value stored in
$SC_DEF AULT_FEED is used.
The setting data is evaluated at the start of the part program allowing for the feed type ac-
tive at the time (see $MC_GCODE_RESET_VALUES and/or $MC_EX-
TERN_GCODE_RESET_VALUES).
42140 DEFAULT_SCALE_FACTOR_P
SD number Default scale factor for address P
Default setting: 0 Minimum input limit: --99999999 Maximum input limit: 99999999
Changes effective IMMEDIATELY Protection level: 7/7 Unit: --
Data type: DWORD Applies with effect from SW version: 5.2
Meaning: This machine data applies in combination with external programming languages.
It is effective with $MN_MM_EXTERN_LANGUAGE = 1.
If no scale factor P is programmed in the block, the value in this
machine data is applied.
42150 DEFAULT_ROT_FACTOR_R
SD number Default angle of rotation R
Default setting: 0 Minimum input limit: 0 Maximum input limit: 360
Changes effective IMMEDIATELY Protection level: 2/7 Unit: degree
Data type: DOUBLE Applies with effect from SW version:
Meaning: When commanding coordinate rotation G68 without specifying an angle of rotation, the
value set to this setting data is applied.
42160 EXTERN_FIXED_FEEDRATE_F1_F9
SD number F1 digit feed F1 -- F9
Default setting: 0 Minimum input limit: 0 Maximum input limit:
Changes effective IMMEDIATELY Protection level: 2/7 Unit: mm/min
Data type: DOUBLE Applies with effect from SW version:
Meaning: Pre--defined feedrates which are selected by commanding F1 -- F9 when G01 is active.
