Machine and Setting Data

D.4 Channel-specific setting data

04.07

D-238

SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition

42520 CORNER_SLOWDOWWN_START

SD number Distance before corner

Default setting: 0 Minimum input limit 0 Maximum input limit: arbitrary

Change effective immediately Protection level: 7/7 Unit POSN_LIN

Data type: DOUBLE Applies with effect from SW version: 6

Meaning: Path length as from which the feed before the corner at G62 is reduced.

42522 CORNER_SLOWDOWN_END

SD number Distance after corner

Default setting: 0 Minimum input limit: 0 Maximum input limit:: arbitrary

Change effective immediately Protection level: 7/7 Unit: POSN_LIN

Data type: DOUBLE Applies with effect from SW version: 6

Meaning: Path length as from which the feed after a corner at G62 remains reduced.

42524 CORNER_SLOWDOWN_OVR

SD number Feed override at corner with G62

Default setting: 0 Minimum input limit: 0 Maximum input limit: arbitrary

Change effective immediately Protection level: 7/7 Unit: PERCENT

Data type: DOUBLE Applies with effect from SW version: 6

Meaning: Override by which the feed at the corner G62 is multiplied.

42526 CORNER_SLOWDOWN_CRIT

SD number Criterium for corner detection with G62

Default setting: 0 Minimum input limit: 0 Maximum input limit: arbitrary

Change effective immediately Protection level: 7/7 Unit: POSN_ROT

Data type: DOUBLE Applies with effect from SW version: 6

Meaning: Angle as from which a corner at feed reduction with G62, G21 is taken into account.

43340 EXTERN_REF_POSITION_G30_1

MD number Reference point position for G30.1

Default setting: Minimum input limit: Maximum input limit:

Changes effective immediately Protection level: Unit:

Data type: DOUBLE Applies with effect from SW version:

Meaning: Setting data

Reference point position for G30.1.

This setting data is evaluated in CYCLE328.
