Movement Control Commands
3.6 S, T, M, and B functions
04.07
3-88
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
M30 (end of tape)
Normally, M30 is specified at the end of tape. When M30 is executed during auto-
matic operation, automatic operation ends after the commands specified with M30
in the same block have been completed. The NC is reset and the tape is rewound.
The state after the execution of M30 varies with each machine. For details, refer to
the instruction manuals published by the machine tool builder.
Note
When M00, M01, M02, or M30 is specified, the NC stops buffering. For these
M codes, the NC output the independent decode signal in addition to the M2-digit
BIN code.
Note
Refer to the manuals published by the machine tool builder concerning whether or
not the spindle and/or coolant supply is stopped by the M00, M01, M02, and M30.
3.6.4 Internally processed M codes
M codes in the range of M90 to M99 are processed by the NC.
Table 3-15 Internally processed M codes
M code
Function
M98 Subprogram call
M99 End of subprogram
3.6.5 Macro call via M functio n
Similar to G65, a macro can be called via M numbers.
The 10 M-function replacement is configured via machine data
10814: $MN_EXTERN_M_NO_MAC_CYCLE and
10815: $MN_EXTERN_M_NO_MAC_CYCLE_NAME.
The parameters are transferred as with G65. Repeat procedures can be program-
med with address L.
