Siemens SINUMERIK 802D sl Programming Manual

G Code Table
C.1 G code table
04.07
C-213
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Table C-1 G code table
G code 802D sl840D slDescription
G56 3 Select zero offset x x
G57 4 Select zero offset x x
G58 5 Select zero offset x x
G59 6 Select zero offset x x
G54P{1...48} 1 Extended zero offsets x x
G54.1 7 Extended zero offset x x
G54 P0 1 “externel zero offsets EXOFS” x x
Group 15
G61 1 Exact stop modal x x
G62 4 Automatic corner override x x
G63 2 Tapping mode x x
G64
1)
3
Continuous--path mode x x
Group 16
G68
2)
1
Coordinate rotation ON, 2D/3D x -- --
G69
2)
2
Coordinate rotation OFF x -- --
Group 17
G15
1)
1
Polar coordinates off x x
G16 2 Polar coordinates on x x
Group 18 (non--modal)
G04 1 Dwell x x
G05 18 High--speed cycle cutting x x
G05.1
2)
22
High--speed cycle --> Calling CYCLE305 x x
G07.1
2)
16
Cylindrical interpolation x x
G08 12 Look--ahead control x -- --
G09 2 Exact stop x x
G10
2)
3
Write zero offset/tool offset x x
G10.6 17 Lift off from contour (POLF) x x
G11 4 Terminate parameter input x x
G27 13 Referencing check x x
G28 5 Approach 1st reference point x x
G30 6 Approach 2nd/3rd/4th reference point x x
G30.1 19 Floating reference position x x
G31 7 Measurement with touch--trigger probe x x
G52 8 Additive zero offset x x
G53 9 Approach position in machine coordinate system x x
G60 22 Oriented positioning x x
