G Code Table
C.1 G code table
04.07
C-214
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
Table C-1 G code table
G code 802D sl840D slDescription
G65
2)
10
Call macro x x
G72.1
2)
14
Contour repeating -- rotational copy x -- --
G72.2
2)
15
Contour repeating -- linear copy x -- --
G92 11 Preset actual value memory / spindle speed limitation x x
G92.1 21 Delete actual value memeory, reset of WCS x x
Group 22
G50.1 1 Programmable mirror image cancel x x
G51.1 2 Programmable mirror image x x
Group 25
G13.1 1 Polar coordinate interpolation mode cancel x x
G12.1 2 Polar coordinate interpolation mode x x
Group 31
G290
1)
1
Select Siemens mode x x
G291 2 Select ISO dialect mode x x
x means that G--Code is applicable, ---- means that G--Code is not applicable
Note: In general, the NC establishes the G code modes identified by 1), when the power is
turned ON or when the NC is reset. However, please refer to the machine tool builders
documentation for actual setting.
The G codes identified by 2) are optional. Please refer to the machine tool builders
documentation for the availability of the function.
To Next Page
