Siemens SINUMERIK 802D sl Programming Manual

Machine and Setting Data
D.2 Channel-specific machine data
04.07
D-235
© Siemens AG 2007 All rights reserved
SINUMERIK 802D sl/840D/840D sl/840Di/840Di sl/810D ISO Milling (PGM) -- 04.07 Edition
24006 CHSFRAME_RESET_MASK
MD number Active system frames after reset
Default setting: 0 Minimum input limit: 0 Maximum input limit: 0x7FF
Changes effective after RESET Protection level: 2/7 Unit: --
Data type: DWORD Applies with effect from SW version: 5.2
Meaning: Bit mask used for the reset setting of the channel--specific system frames included in the
channel.
Bit 0: System frame for actual value setting and scratching is active after
reset.
Bit 1: System frame for external work offset is active after reset.
Bit 2: Reserved, for TCARR and PAROT see $MC_GCODE_RESET_VALUES[].
Bit 3: Reserved, for TOROT and TOFRAME see $MC_GCODE_RESET_VALUES[].
Bit 4: System frame for workpiece reference points is active after reset.
Bit 5: System frame for cycles is active after reset.
Bit 6: Reserved; reset behavior dependent on $MC_RESET_MODE_MASK.
Bit 7: System frame $P_ISO1FR (ISO G51.1 Mirror) is active after reset.
Bit 8: System frame $P_ISO2FR (ISO G68 2DROT) is active after reset.
Bit 9: System frame $P_ISO3FR (ISO G68 3DROT) is active after reset.
Bit 10: System frame $P_ISO4FR (ISO G51 Scale) is active after reset.
Related to:
MM_SYSTEM_FRAME_MASK
This MD cannot SINUMERIK 802D sl..
28082 MM_SYSTEM_FRAME_MASK
MD number System frames (SRAM)
Default setting: 0 Minimum input limit: 0 Maximum input limit: 0x7FF
Changes effective after Power ON Protection level: 2/7 Unit: --
Data type: DWORD Applies with effect from SW version: 5.2
Meaning: Bit mask for configuring channel--specific system frames included in the channel.
The following applies:
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7: System frame for $P_ISO1FR for ISO G51.1 Mirror
Bit 8: System frame for $P_ISO2FR for ISO G68 2DROT
Bit 9: System frame for $P_ISO3FR for ISO G68 3DROT
Bit 10: System frame for $P_ISOFR for ISO G51 Scale
This MD cannot SINUMERIK 802D sl..
