Siemens SINUMERIK 828D Programming Manual

Transformations
6.8 Kinematic transformation
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
369
With groove wall offset (transformation type 513):
Kinematics as above, but an additional longitudinal axis parallel to the peripheral direction
The linear axes are positioned perpendicular to one another.
The velocity control makes allowance for the limits defined for the rotations.
<RU&0
=RU=0
<0
$60
;0
Groove traversing-section
In the case of axis configuration 1, longitudinal grooves along the rotary axis are subject to
parallel limits only if the groove width corresponds exactly to the tool radius.
Grooves in parallel to the periphery (transverse grooves) are not parallel at the beginning
and end.
75$)2B7<3(BQ 
75$)2B7<3(BQ 
SDUDOOHOOLPLWHGORQJLWXGL
QDOVORWZLWKVORWZDOO
FRPSHQVDWLRQ
ZLWKRXWJURRYHZDOORIIVHW
7UDQVYHUVHJURRYH
/RQJLWXGLQDOVORW

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
