Tables
16.1 Instructions
Job planning
728 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
FXS Travel to fixed stop ON m
PGsl
FXST Torque limit for travel to fixed stop m
PGsl
FXSW Monitoring window for travel to fixed
stop
PGsl
FZ Tooth feedrate m
PGsl
G0 Linear interpolation with rapid traverse
(rapid traverse motion)
m
PGsl
G1
3)
Linear interpolation with feedrate (linear
interpolation)
m
PGsl
G2 Circular interpolation clockwise m
PGsl
G3 Circular interpolation counter-clockwise m
PGsl
G4 Dwell time, preset s
PGsl
G5 Oblique plunge-cut grinding s
PGAsl
Inclined axis (TRAANG) (Page 372)
G7 Compensatory motion during oblique
plunge-cut grinding
s
PGAsl
Inclined axis (TRAANG) (Page 372)
G9 Exact stop - deceleration s
PGsl
G17
3)
Selection of working plane X/Y m
PGsl
G18 Selection of working plane Z/X m
PGsl
G19 Selection of working plane Y/Z m
PGsl
G25 Lower working area limitation s
PGsl
G26 Upper working area limitation s
PGsl
G33 Thread cutting with constant lead m
PGsl
G34 Thread cutting with linear increasing
lead
m
PGsl
G35 Thread cutting with linear decreasing
lead
m
PGsl
G40
3)
Tool radius compensation OFF m
PGsl
