Tables
16.1 Instructions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
729
Operation Meaning W
1)
Description see
2)
G41 Tool radius compensation left of
contour
m PGsl
G42 Tool radius compensation right of
contour
m PGsl
G53 Suppression of current work offset
(non-modal)
s PGsl
G54 1st adjustable work offset m PGsl
G55 2nd adjustable work offset m PGsl
G56 3rd adjustable work offset m PGsl
G57 4th adjustable work offset m PGsl
G58 Axial programmable work offset,
absolute, coarse offset
s PGsl
G59 Axial programmable work offset,
additive, fine offset
s PGsl
G60
3)
Exact stop - deceleration m PGsl
G62 Corner deceleration at inside corners
when tool radius offset is active (G41,
G42)
m PGAsl
Feed reduction with corner deceleration (FENDNORM,
G62, G621) (Page 273)
G63 Tapping with compensating chuck s PGsl
G64 Continuous-path mode m PGsl
G70 Inch dimensions for geometric
specifications (lengths)
m PGsl
G71
3)
Metric dimensions for geometric
specifications (lengths)
m PGsl
G74 Search for reference s PGsl
G75 Fixed point approach s PGsl
G90
3)
Absolute dimensions m/s PGsl
G91 Incremental dimensions m/s PGsl
G93 Inverse-time feedrate rpm m PGsl
G94
3)
Linear feedrate F in mm/min or
inch/min and degree/min
m PGsl
