Tables
16.1 Instructions
Job planning
730 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
G95 Revolutional feedrate F in mm/rev or
inch/rev
m
PGsl
G96 Constant cutting rate (as for G95) ON m
PGsl
G97 Constant cutting rate (as for G95) OFF m
PGsl
G110 Pole programming relative to the last
programmed setpoint position
s
PGsl
G111 Pole programming relative to zero of
current workpiece coordinate system
s
PGsl
G112 Pole programming relative to the last
valid pole
s
PGsl
G140
3)
SAR approach direction defined by
G41/G42
m
PGsl
G141 SAR approach direction to left of
contour
m
PGsl
G142 SAR approach direction to right of
contour
m
PGsl
G143 SAR approach direction tangent-
dependent
m
PGsl
G147 Soft approach with straight line s
PGsl
G148 Soft retraction with straight line s
PGsl
G153 Suppression of current frames including
basic frame
s
PGsl
G247 Soft approach with quadrant s
PGsl
G248 Soft retraction with quadrant s
PGsl
G290 Switch over to SINUMERIK mode ON m
FBW
G291 Switch over to ISO2/3 mode ON m
FBW
G331 Rigid tapping, positive lead, clockwise m
PGsl
G332 Rigid tapping, negative lead, counter-
clockwise
m
PGsl
G340
3)
Spatial approach block (depth and in
plane at the same time (helix))
m
PGsl
G341 Initial infeed on perpendicular axis (z),
then approach in plane
m
PGsl
G347 Soft approach with semicircle s
PGsl
