Tables
16.1 Instructions
Job planning
734 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
IDS Identifier for modal static synchronized
actions
PGAsl
Area of validity and machining sequence (ID, IDS)
(Page 551)
IF Introduction of a conditional jump in the
part program/technology cycle
PGAsl
Program loop with alternative (IF, ELSE, ENDIF)
(Page 99)
INDEX Define index of character in input string
PGAsl
Search for character/string in the string (INDEX,
RINDEX, MINDEX, MATCH) (Page 81)
INIPO Initialization of variables at POWER ON
PGAsl
Definition of user variables (DEF) (Page 23)
INIRE Initialization of variables at reset
PGAsl
Definition of user variables (DEF) (Page 23)
INICF Initialization of variables at NewConfig
PGAsl
Definition of user variables (DEF) (Page 23)
INIT Selection of a particular NC program for
execution in a particular channel
PGAsl
Program coordination (INIT, START, WAITM, WAITMC,
WAITE, SETM, CLEARM) (Page 106)
INITIAL Generation of an INI file across all
areas
PGAsl
Working memory (CHANDATA, COMPLETE, INITIAL)
(Page 212)
INT Data type: Integer with sign
PGAsl
Definition of user variables (DEF) (Page 23)
INTERSEC Calculate intersection between two
contour elements
PGAsl
Determine point of intersection between two contour
elements (INTERSEC) (Page 702)
INVCCW Trace involute, counter-clockwise m
PGsl
INVCW Trace involute, clockwise m
PGsl
INVFRAME Calculate the inverse frame from a
frame
FB1(K2)
IP Variable interpolation parameter
PGAsl
Indirect programming (Page 55)
IPOBRKA Motion criterion from braking ramp
activation
m
PGAsl
Programmed end-of-motion criterion (FINEA,
COARSEA, IPOENDA, IPOBRKA, ADISPOSA)
(Page 274)
IPOENDA End of motion when “IPO stop” reached m
PGAsl
Programmed end-of-motion criterion (FINEA,
COARSEA, IPOENDA, IPOBRKA, ADISPOSA)
(Page
274)
IPTRLOCK Freeze start of the untraceable program
section at next machine function block
m
PGAsl
Preventing program position for SERUPRO
(IPTRLOCK, IPTRUNLOCK) (Page 472)
