Siemens SINUMERIK 828D

Tables
16.1 Instructions
Job planning
738 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
MEAC Continuous measurement without
deletion of distance-to-go
s PGAsl
Extended measuring function (MEASA, MEAWA,
MEAC) (option) (Page 263)
MEAFRAME Frame calculation from measuring
points
PGAsl
Frame calculation from three measuring points in space
(MEAFRAME) (Page 298)
MEAS Measurement with touch-trigger probe s PGAsl
Measurements with touch trigger probe (MEAS,
MEAW) (Page 260)
MEASA Measurement with deletion of distance-
to-go
s PGAsl
Extended measuring function (MEASA, MEAWA,
MEAC) (option) (Page
263)
MEASURE Calculation method for workpiece and
tool measurement
FB2(M5)
Measurements with touch trigger probe (MEAS,
MEAW) (Page 260)
MEAW Measurement with touch-trigger probe
without deletion of distance-to-go
s PGAsl
Measurements with touch trigger probe (MEAS,
MEAW) (Page
260)
MEAWA Measurement without deletion of
distance-to-go
s PGAsl
Extended measuring function (MEASA, MEAWA,
MEAC) (option) (Page 263)
MI Access to frame data: Mirroring PGAsl
Reading and changing frame components (TR, FI, RT,
SC, MI) (Page 290)
MINDEX Define index of character in input string PGAsl
Search for character/string in the string (INDEX,
RINDEX, MINDEX, MATCH) (Page 81)
MINVAL Smaller value of two variables (arithm.
function)
PGAsl
Variable minimum, maximum and range (MINVAL,
MAXVAL and BOUND) (Page
70)
MIRROR Programmable mirroring s PGAsl
MMC Call the dialog window interactively
from the part program on the HMI
PGAsl
Interactively call the window from the part program
(MMC) (Page
682)
MOD Modulo division PGAsl
Arithmetic functions (Page 63)
MODAXVAL Determine modulo position of a modulo
rotary axis
PGAsl
Axis functions (AXNAME, AX, SPI, AXTOSPI, ISAXIS,
AXSTRING, MODAXVAL) (Page 661)
MOV Start positioning axis PGAsl
Start/stop axis (MOV) (Page 597)
MSG Programmable messages m PGsl
MVTOOL Language command to move tool FBW
