Tables
16.1 Instructions
Job planning
742 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Operation Meaning W
1)
Description see
2)
ORIVIRT2 Orientation angle via virtual orientation
axes (definition 1)
m PGAsl
Programming orientation axes (ORIAXES, ORIVECT,
ORIEULER, ORIRPY, ORIRPY2, ORIVIRT1,
ORIVIRT2) (Page 333)
ORIWKS
3)
Tool orientation in the workpiece
coordinate system
m PGAsl
Orientation axis reference (ORIWKS, ORIMKS)
(Page 331)
OS Oscillation on/off PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page 633)
OSB Oscillating: Starting point m FB2(P5)
OSC Continuous tool orientation smoothing m PGAsl
Tool orientation (ORIC, ORID, OSOF, OSC, OSS,
OSSE, ORIS, OSD, OST) (Page
423)
OSCILL Axis: 1 - 3 infeed axes m PGAsl
Oscillation controlled by synchronized actions (OSCILL)
(Page 639)
OSCTRL Oscillation options m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page 633)
OSD Smoothing of tool orientation by
specifying smoothing distance with SD
m PGAsl
Tool orientation (ORIC, ORID, OSOF, OSC, OSS,
OSSE, ORIS, OSD, OST) (Page 423)
OSE Oscillation end position m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page 633)
OSNSC Oscillating: Number of spark-out cycles m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page 633)
OSOF
3)
Tool orientation smoothing OFF m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page
633)
OSP1 Oscillating: Left reversal point m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page
633)
OSP2 Oscillation right reversal point m PGAsl
Asynchronous oscillation (OS, OSP1, OSP2, OST1,
OST2, OSCTRL, OSNSC, OSE, OSB) (Page
633)
OSS Tool orientation smoothing at end of
block
m PGAsl
Tool orientation (ORIC, ORID, OSOF, OSC, OSS,
OSSE, ORIS, OSD, OST) (Page 423)
OSSE Tool orientation smoothing at start and
end of block
m PGAsl
Tool orientation (ORIC, ORID, OSOF, OSC, OSS,
OSSE, ORIS, OSD, OST) (Page
423)
